Hideout Travel Trailer Floorplans
2026 Hideout
210RL
1/1
Specifications
RV Type: Travel Trailer
Sleeping Capacity: 5
Number of Propane Tanks: 2
Refrigerator Size: 10.70 cu ft
2026 Hideout
212RKS
1/1
Specifications
RV Type: Travel Trailer
Shipping Weight: 5,360 lb.
Carrying Capacity: 2,140 lb.
Hitch: 620 lb.
Length: 25 ft 6 in
Height: 10 ft 8 in
Tire-Size: ST205/75R14D
Fresh Water: 45 gal
Gray Water: 69 gal
Waste Water: 30 gal
Sleeping Capacity: 5
Number of Propane Tanks: 2
LPG: 40 lb.
Refrigerator Size: 10.70 cu ft
2026 Hideout
230BH
1/1
Specifications
RV Type: Travel Trailer
Shipping Weight: 4,776 lb.
Carrying Capacity: 1,724 lb.
Hitch: 625 lb.
Length: 27 ft 6 in
Height: 10 ft 8 in
Tire-Size: ST205/75R14D
Fresh Water: 41 gal
Gray Water: 39 gal
Waste Water: 30 gal
Sleeping Capacity: 9
Number of Propane Tanks: 2
LPG: 40 lb.
Refrigerator Size: 10.70 cu ft
2026 Hideout
262BHS
1/1
Specifications
RV Type: Travel Trailer
Shipping Weight: 6,205 lb.
Carrying Capacity: 1,495 lb.
Hitch: 725 lb.
Length: 30 ft 11 in
Height: 11 ft 1 in
Tire-Size: ST205/75R14D
Fresh Water: 41 gal
Gray Water: 39 gal
Waste Water: 30 gal
Sleeping Capacity: 9
Number of Propane Tanks: 2
LPG: 40 lb.
Refrigerator Size: 10.70 cu ft
2026 Hideout
288BRS
1/1
Specifications
RV Type: Travel Trailer
Length: 32 ft 11 in
Height: 11 ft 3 in
Tire-Size: ST225, 15D
Fresh Water: 45 gal
Gray Water: 41 gal
Waste Water: 30 gal
Sleeping Capacity: 9
Number of Propane Tanks: 2
LPG: 40 lb.
Refrigerator Size: 10.70 cu ft
2026 Hideout Mini
195RBS
1/1
Specifications
RV Type: Travel Trailer
Shipping Weight: 4,020 lb.
Carrying Capacity: 1,600 lb.
Hitch: 520 lb.
Length: 23 ft 4 in
Height: 9 ft 10 in
Tire-Size: ST225/75R15E
Fresh Water: 45 gal
Gray Water: 34 gal
Waste Water: 34 gal
Sleeping Capacity: 3
Number of Propane Tanks: 1
LPG: 20 lb.
Refrigerator Size: 10 cu ft
2026 Hideout Mini
199BHS
1/1
Specifications
RV Type: Travel Trailer
Shipping Weight: 4,085 lb.
Carrying Capacity: 1,510 lb.
Hitch: 495 lb.
Length: 23 ft 4 in
Height: 9 ft 10 in
Tire-Size: ST225/75R15E
Fresh Water: 45 gal
Gray Water: 34 gal
Waste Water: 34 gal
Sleeping Capacity: 7
Number of Propane Tanks: 1
LPG: 20 lb.
Refrigerator Size: 10 cu ft
2026 Hideout Mini
120BT
1/1
Specifications
RV Type: Travel Trailer
Shipping Weight: 2,630 lb.
Carrying Capacity: 870 lb.
Hitch: 400 lb.
Length: 15 ft 11 in
Height: 9 ft 10 in
Tire-Size: ST205/75R14D
Fresh Water: 21 gal
Gray Water: 34 gal
Waste Water: 34 gal
Sleeping Capacity: 2
Number of Propane Tanks: 1
LPG: 20 lb.
Refrigerator Size: 3.30 cu ft
2026 Hideout Mini
123BB
1/1
Specifications
RV Type: Travel Trailer
Shipping Weight: 2,635 lb.
Carrying Capacity: 865 lb.
Hitch: 375 lb.
Length: 15 ft 11 in
Height: 9 ft 10 in
Tire-Size: ST205/75R14D
Fresh Water: 21 gal
Gray Water: 34 gal
Waste Water: 34 gal
Sleeping Capacity: 4
Number of Propane Tanks: 1
LPG: 20 lb.
Refrigerator Size: 3.30 cu ft
2026 Hideout Mini
161BH
1/1
Specifications
RV Type: Travel Trailer
Shipping Weight: 3,085 lb.
Carrying Capacity: 1,255 lb.
Hitch: 340 lb.
Length: 20 ft 6 in
Height: 9 ft 10 in
Tire-Size: ST205/75R14D
Fresh Water: 21 gal
Gray Water: 34 gal
Waste Water: 34 gal
Sleeping Capacity: 6
Number of Propane Tanks: 1
LPG: 20 lb.
Refrigerator Size: 3.30 cu ft
2026 Hideout Mini
166RB
1/1
Specifications
RV Type: Travel Trailer
Shipping Weight: 3,090 lb.
Carrying Capacity: 1,295 lb.
Hitch: 385 lb.
Height: 9 ft 10 in
Tire-Size: ST205/75R14D
Fresh Water: 21 gal
Gray Water: 34 gal
Waste Water: 34 gal
Sleeping Capacity: 4
Number of Propane Tanks: 1
LPG: 20 lb.
Refrigerator Size: 3.30 cu ft
2026 Hideout Max
29HAVEN
1/1
Specifications
RV Type: Travel Trailer
Shipping Weight: 7,340 lb.
Carrying Capacity: 2,160 lb.
Hitch: 1,055 lb.
Length: 33 ft 11 in
Height: 11 ft 3 in
Tire-Size: ST225/75R15D
Fresh Water: 54 gal
Gray Water: 78 gal
Waste Water: 30 gal
Sleeping Capacity: 4
Number of Propane Tanks: 2
LPG: 40 lb.
Refrigerator Size: 10.70 cu ft
2026 Hideout Max
310XBR
1/1
Specifications
RV Type: Travel Trailer
Shipping Weight: 8,325 lb.
Carrying Capacity: 2,830 lb.
Hitch: 955 lb.
Length: 35 ft 11 in
Height: 11 ft 3 in
Tire-Size: ST225/75R15D
Fresh Water: 54 gal
Gray Water: 39 gal
Waste Water: 39 gal
Sleeping Capacity: 9
Number of Propane Tanks: 2
LPG: 40 lb.
Refrigerator Size: 10.70 cu ft
2026 Hideout Max
31SUNROOM
1/1
Specifications
RV Type: Travel Trailer
Shipping Weight: 7,530 lb.
Carrying Capacity: 1,970 lb.
Hitch: 815 lb.
Length: 35 ft 11 in
Height: 11 ft 1 in
Tire-Size: ST225/75R15D
Fresh Water: 54 gal
Gray Water: 39 gal
Waste Water: 30 gal
Sleeping Capacity: 4
Number of Propane Tanks: 2
LPG: 40 lb.
Refrigerator Size: 10.70 cu ft
